500-800tph stone crusher plant

Capacity:500-800tph stone crusher plant

CRUSHING MATERIAL:limestone, granite, cobble, dolomite, bluestone, iron ore, construction waste, glass, cement clinker, etc

APPLIED FIELD:This crusher widely used in quarry, mining, coal.

Introduction: Inquiry Now

500-800TPH crushing plant features for its large scope production, good performance, convenient operation, this line can achieve high reduction ratio with great output.

The third largest Jaw crusher model PE900X1200 works as primary crushing, its over sized feed opening & unique Jaw plates make it readily crush 750mm into small sizes.

All the spare parts assembled are of top quality (bearing, motor, eccentric shaft, screen mesh, etc.), this ensure the stable working status for all the equipments.

Secondary crushing process is performed by two sets of impact crusher model PF-1315 which is superior in its larger feed opening and rotor, the final product sizes can be controlled through regulating impact-bracket.

Tertiary crusher such as VSI or washing machine may work as additional mining equipments to diversify the final products, meanwhile, tailor-made dust catcher or dust cover maybe the last step to perfect this line on the basis of environmental protection. The final products are of regular cube shape, high compressive strength, needle shape take up small proportion, no inner-cracks. They are quite suitable for speedway, bridge, tunnel and other construction projects.

Working Principle: Inquiry Now


1. Low energy consumption

2. Easy maintenance

3. All equipments made of high quality raw material

4. Customized equipment con

Parameters: Inquiry Now

No. Item Model Quantity (set)
1.  Big Hopper Matched 2
2.  Vibrating feeder GZT1148 2
3.  Jaw crusher PE750x1060 2
4.  Belt conveyor B1000x28m 2
5.  Symons cone crusher PSGB1325 2
6.  High efficiency fine crusher PCX1214 4
7.  Belt conveyor B1000x30m 6
8.  Belt conveyor B1000x34m 2
9.  Vibrating screen 3YK2170 6
10.  Belt conveyor B800x40m 1
11.  Belt conveyor B800x25m 2
12.  Belt conveyor B800x5m 2
13.  Belt conveyor B800x36m 1
14.  Belt conveyor B800x12m 2
15.  Electrical control cabinet matched
